HW, Z 2, with guide ring on top
WO 203-1
D
mm |
GL
mm |
NL
mm |
S
mm |
DRI |
ID |
|
| 28 |
80 |
25 |
12x40 |
RL |
072697 |
|
RPM:
n = 18000 - 27000 min-1
Spare parts Close
| BEZ |
ABM
mm |
ID |
|
| Ball bearing guide |
28x8.3x15. 11° |
072712 |
|
HW, Z 2, with guide on bottom
AO 640-1
D
mm |
GL
mm |
NL
mm |
S
mm |
DRI |
ID |
|
| 19 |
74 |
25 |
12x40 |
RL |
072709 |
|
RPM:
n = 18000 - 27000 min-1
Spare parts
| BEZ |
ABM
mm |
ID |
|
| Ball bearing guide |
19x8x4.76 |
072630 |
|
| Ball bearing guide |
28x8.3x15. 11° |
072712 |
|
| Screw Torx® 15 |
M4x8 |
007407 |
|
HW turnblade, Z 2, with guide ring on bottom
AO 640-1
D
mm |
GL
mm |
NL
mm |
S
mm |
DRI |
ID |
|
| 21 |
89 |
30 |
12x40 |
RL |
072220 |
|
RPM:
n = 18000 - 27000 min-1
Spare knives
| BEZ |
ABM
mm |
VE
PCS |
ID |
|
| Turnblade knife |
29.5x12x1.5 |
10 |
005161 |
|
Spare parts
| BEZ |
ABM
mm |
ID |
|
| Ball bearing guide |
15.88x21x8.1 |
072255 |
|
| Nut |
M6 |
005651 |
|
| Oval head screw Torx® 15 |
M4x6 |
006225 |
|
| Torx® key |
Torx® 15 |
005457 |
|
|
