SB 26.4 - 98 mm
SW 531-1-01
D
mm |
SB
mm
|
VSB
mm
|
BO
mm
|
BOmax
mm
|
Z
|
V
|
n
min-1
|
ID
|
|
|
160
|
20
|
26.4 - 38
|
30
|
45
|
4
|
4
|
4900 - 9500
|
024456
|
|
|
160
|
20
|
26.4 - 38
|
50
|
50
|
4
|
4
|
4900 - 9500
|
024458
|
|
|
160
|
50
|
56.4 - 98
|
40
|
45
|
4
|
4
|
4900 - 9500
|
024455
|
|
Spare knives
Part-no.
|
BEZ
|
ABM
mm
|
QAL
|
VE
PCS
|
ID
|
|
|
1
|
Turnblade knife
|
19.7x8x1.5
|
HW-30F
|
10
|
005071
|
|
|
1
|
Turnblade knife
|
50x8x1.5
|
HW-30F
|
10
|
005075
|
|
|
1
|
Turnblade knife
|
30x8x1.5
|
HW-30F
|
10
|
005072
|
|
|
2
|
Turnblade spur VS2
|
19x19x2
|
HW-F
|
10
|
005115
|
|
Spare parts
Part-no.
|
BEZ
|
ABM
mm
|
ID
|
|
|
3
|
Clamping wedge
|
18x18.75x8.27
|
009671
|
|
|
3
|
Clamping wedge
|
48x18.75x8.27
|
009677
|
|
|
3
|
Clamping wedge
|
28x18.75x8.27
|
009673
|
|
|
4
|
Countersink screw, Torx® 20
|
M6x0,5x4,9
|
006243
|
|
|
5
|
Clamping screw, Torx® 25
|
M6x18,5
|
007818
|
|
|
6
|
Washer
|
9/6.2x1.2
|
006753
|
|
|
7
|
Torx® key
|
Torx® 20
|
117503
|
|
|
8
|
Torx® key
|
Torx® 25
|
117504
|
|
|
|
Setting gauge
|
0,3/0,8
|
005374
|
|
|
