| Profile cutterhead set ProfilCut Panel raising TH-481 |
|
|
| |
| Thông số kỹ thuật: |
Panel raising depth max. 54 mm
WE 550-2-50, SG 599-2-50
| Tool Type |
P |
ABM
mm |
QAL |
Z |
nmax
min-1 |
ID |
|
| Cutterhead |
1 |
124x20/36x20 |
MC |
2/2 |
12 300 |
041223 |
|
| Cover plate |
|
46x9.5x20 |
MC |
|
|
007925 |
|
| Cutterhead mounted on arbor |
1 |
1 part |
MC |
2/2 |
12 300 |
426030 |
|
Unless stated otherwise, tools are right hand rotation.
Cutter arbor see section 8 Clamping systems.
Spare knives
| Part-no. |
BEZ |
P |
ABM
mm |
QAL |
VE
PCS |
ID |
|
| |
Turnblade knife |
|
12x12x1.5 |
HW-05 |
10 |
005081 |
|
| 1 |
Profile knife profile 1 |
1 |
20x27x2 |
MC |
|
007560 |
|
| 1 |
Profile knife profile 2 |
2 |
20x27x2 |
MC |
|
007561 |
|
| 1 |
Profile knife profile 3 |
3 |
20x27x2 |
MC |
|
007562 |
|
| 1 |
Profile knife profile 4 |
4 |
20x27x2 |
MC |
|
007563 |
|
| 1 |
Profile knife profile 5 |
5 |
20x27x2 |
MC |
|
007564 |
|
| 2 |
Turnblade knife |
|
40x8x1.5 |
HW-30F |
10 |
005074 |
|
Spare parts
| Part-no. |
BEZ |
P |
ABM
mm |
ID |
|
| 3 |
Clamping wedge profiled |
1-5 |
18x37.46x8.27 |
009722 |
|
| 4 |
Clamping wedge |
Panel raising |
37x16.8x7.25 |
009577 |
|
| 5 |
Clamping screw, Torx® 25 |
|
M6x18,5 |
007818 |
|
| 6 |
Washer |
|
D9x1,2 |
006747 |
|
| 7 |
Torx® key |
|
Torx® 25 |
117504 |
|
| |
Oval head screw Torx® 15 |
|
M4x6 |
006225 |
|
| |
Torx® key |
|
Torx® 15 |
117507 |
|
| |
Cover plate |
|
46x9.5x20 |
007925 |
|
Jointing
WW 200-2
| Tool Type |
ABM
mm |
QAL |
Z |
ID |
|
| Jointing cutterhead |
30/46x12/22.5x20 |
HW |
2 |
041221 |
|
|
|
|
